Astrographs by AstroSysteme
Austria are
absolute High End Devices. We use only the prime components that
are available at present. Uncompromising optical design of Dipl.phys.
Philipp Keller, latest CFK manufacture techniques. All ASA
astrographs have Sital primary and secondary mirrors of LOMO,
Lambda 1/16 PV, 1/70 RMS with interferrogram. If not otherwise
declared, also the correctors come from LOMO in St. Petersburgh.
The tubes consist of high quality CFK-sandwich construction with
sight carbon fibre structure, all aluminium parts are CNC-milled
and anodized (Tube Rings are optional).
ASA Astrograph N f 2,2 (only on order)
Type
of Device
|
Astrograph
N8 f2,2 |
Astrograph
N10 f2,2 |
Astrograph
N12 f2,2 |
Aperture
|
203 mm |
254 mm |
305 mm |
Focal length
|
450 mm |
560 mm |
675 mm |
Corrector
|
4 Lens 2" |
4 Lens 2" |
4 Lens 2" |
Corr. image
circle
|
13 mm |
13 mm |
13 mm |
| Matrix Spot
Diagram |
Spot |
Spot |
Spot |
Focuser
|
2" JMI NGF
DX-1 |
2" JMI NGF
DX-1 |
2" JMI NGF
DX-1 |
| Tube |
CFK sandwich |
CFK sandwich |
CFK sandwich |
Weight
|
7 kg |
9 kg |
13 kg |
|
ASA Astrograph N f 3,8
Prices for LOMO Optics on request
|
Larger devices on request.
.
|
ASA Astrograph N f 2,75
Type
of Device
|
Astrograph
N8 f2,75 |
Astrograph
N10 f2,75 |
Astrograph
N12 f2,75 |
Aperture
|
203 mm |
254 mm |
305 mm |
Focal length
|
560 mm |
700 mm |
840 mm |
| Corrector |
4 lenses
2" |
4 lenses
2" |
4 lenses
2" |
Corr. image
circle
|
22 mm |
22 mm |
22 mm |
Focuser
|
2" JMI
NGF DX-1 |
2" JMI
NGF DX-1 |
2" JMI
NGF DX-1 |
| Tube |
CFK sandwich |
CFK sandwich |
CFK sandwich |
Weight
|
7 kg |
10 kg |
14 kg |
LOMO
Optic
Austrian price
without shipping excl. 20 % VAT
|
on request
|
on
request
|
on request
|
|
 |
|
